Superb analog audio quality

Renowned ESS Sabre32™ DAC technology delivers 125 dB dynamic range and extremely low harmonic distortion. Analog performance is driven by decades of engineering expertise in audio interface technology.

Universal connectivity for Mac, PC and iOS

Connect to your Mac, PC or iOS device with 5 Gbps USB 3 (compatible with USB 2), with up to 60 audio channels (28 in and 32 out). Class-compliant firmware means you can plug-and-play with Mac or iOS hosts, no driver needed. Industry standard high-performance drivers work with any audio apps. Connect directly to your iPad™ via USB-C or a standard camera connection kit (Lightning adapter).

60 simultaneous audio channels

Connect all your studio gear, including microphones,
guitars, synths, keyboards, drum machines, outboard
processors, MIDI gear, optical expanders — even a foot pedal.
All 28 inputs and 32 outputs are available simultaneously.

Ultra-low latency performance

Optimized drivers for both Mac and PC deliver renowned, ultra-low latency performance. With
a high-performance DAW such as Digital Performer, the 828 delivers an astonishing round trip
latency (RTL) of ~2 ms (milliseconds) over USB (2 or 3) at 96 kHz with a 32-sample host buffer.

Transparent mic channels and hi-Z guitar inputs

Capture your recorded material in its truest, most natural form with -113 dB THD+N, 115 dB
dynamic range and -129 dBu EIN performance. Each mic channel has individual preamp gain,
pad, 48V phantom power and remote control from your computer or iOS device. Each combo
jack alternately provides a 1/4-inch high-impedance TS guitar input for DI tracking and reamping

DIY guitar re-amping

DI your guitar to the front-panel input, use CueMix's near-zero latency to loop to any output (with
a re-amp adapter, if needed), and record both the dry signal and your mic’d up amp simultaneously. Then
re-amp the dry signal later with different amps and cabs — or amp modeling plug-ins — to
experiment with different tones. No need to re-plug cables between recording and re-amping.

Extra line inputs when you need them

Do you work with compressors and other outboard gear? Each 828 mic input offers a dedicated analog send/return
loop, allowing for both mono or stereo mic channel outboard processing via fully balanced connections. If nothing is
plugged in to a mic input, its return serves as an extra line input with identical signal characteristics to all other line inputs.

Control up to ten analog outputs

Control your 5.1 or 7.1 surround speaker system with a single fader. The Monitor
Group gives you the flexibility to choose any analog outputs you wish to control.

A/B speaker select and talkback

Take control of your recording sessions with the front-panel
talkback switch. Connect two sets of monitors and check
your mixes instantly with front-panel A/B select buttons.

Monitor Mixing with Effects

CueMix 5 for Mac, Windows and iOS gives you
simple, yet comprehensive graphic control over your
mix with attractive graphic mixing, graphic editing
of parametric EQ, and a convenient touch-friendly
interface (on iOS) for quick access to all mixing
features, digitally controlled trims and other settings.

CueMix 5 for iOS

Control all settings and mixing from your
USB host or from an iPhone or iPad running
the CueMix 5 app. You can even use multiple
iOS devices simultaneously. Set a
password for your 828 for network security.

Tech Specs

Computer Connectivity:USB 3.2 Gen 1
Form Factor:Rackmount
Simultaneous I/O:28 x 32
Number of Preamps:2
Phantom Power:Per channel
A/D Resolution:Up to 24-bit/192kHz
Analog Inputs:2 x XLR-1/4" combo (mic/line/Hi-Z), 8 x 1/4" (line)
Analog Outputs:8 x ¼" TRS (line, DC coupled), 2 x XLR (main out)
Digital Inputs:1 x Coax (S/PDIF), 1 x Optical A (ADAT), 1 x Optical B (ADAT/stereo Toslink)
Digital Outputs:1 x Coax (S/PDIF), 1 x Optical A (ADAT), 1 x Optical B (ADAT/stereo Toslink)
Inserts:2 x 1/4" TRS (mic send), 2 x 1/4" TRS (mic return)
Headphones:2 x 1/4" TRS (ESS-driven)
MIDI I/O:In, Out/Thru
USB:1 x USB-C 3.2 Gen 1
Clock I/O:1 x BNC (In, Out/Thru)
Other I/O:1 x 1/4" (footswitch)
Features:3.9" LCD Display
Software:MOTU CueMix 5 app, MOTU Performer Lite, Ableton Live Lite
OS Requirements - Mac:macOS 10.13 or later
OS Requirements - PC:Windows 10 or later
Rack Spaces:1U
Power Supply:Standard IEC AC cable
Height:1.75"
Width:19"
Depth:12.25"
Weight:11 lbs.
